Pressure Range |
-0.1...0...6MPa |
|
Display |
LCD/LED |
|
Medium |
Water, Gas, Oil Purity Medium |
|
Accuracy |
0.1%,0.25%,0.5% F.S optional |
|
Pressure Type |
Gauge (G), Absolute (A), Sealed Gauge (S) |
|
Output |
4～20mA,0～5VDC,1～5VDC,0～10VDoptional |
|
Power Supply |
12～36VDC |
|
Overload Capacity |
150%F.S |
|
Compensated Temperature |
-10-70℃ |
|
Operating Temperature |
0℃～100℃(Customized) |
|
Zero Temp. Drift |
±0.03%FS/℃ |
|
Sensitivity Temp. Drift |
±0.03%FS/℃ |
|
Long Term Stability |
≤0.2%FS/year |
|
Response Speed |
≤1ms(up to 90%FS) |
|
Process Connection |
Flange Connection GB, DIN,ASME,JIS customized |
|
Ingress Protection |
IP65 |
|
CAP -2088FL-ð-ð-ð-ð-ð-ð-ð-ð |
Code | ||||||||
|
Range |
-0.1...0...6MPa |
R | |||||||
|
Customized |
E | ||||||||
|
Type |
Gauge (G) |
G | |||||||
|
Absolute (A) |
A | ||||||||
|
Sealed Gauge (S) |
S | ||||||||
|
Output |
4~20mA |
V1 | |||||||
|
0~5V DC |
V2 | ||||||||
|
1~5V DC |
V3 | ||||||||
|
Hart, RS485,RS232（optional） |
V4 | ||||||||
|
Connection |
GB |
B1 | |||||||
|
ASME |
B2 | ||||||||
|
Customized |
B3 | ||||||||
|
Accuracy |
0.5%FS |
C1 | |||||||
|
0.25%FS |
C2 | ||||||||
|
0.1%FS |
C3 | ||||||||
|
Display |
No display |
D1 | |||||||
|
LCD display |
D2 | ||||||||
|
LED display |
D3 | ||||||||
|
Material |
304SS |
M1 | |||||||
|
306LSS |
M2 | ||||||||
|
Ex-proof |
No explosion-proof |
0 | |||||||
|
Ex | |||||||||
