Specification
| Pressure Range | -0.1～0-0.02～100MPa |
| Display | LCD/LED |
| Medium | Water,Gas,Oil Purity Medium |
| Accuracy | 0.1%,0.25%,0.5% F.S optional |
| Pressure Type | Gauge (G), Absolute (A), Sealed Gauge (S) |
| Output | 4～20mA、0～5VDC、1～5VDC、0～10VDC optional |
| Power Supply | 12～36VDC |
| Overload Capacity | 150%F.S |
| Compensated Temperature | -10-70℃ |
| Operating Temperature | -20℃~65℃ (Higher Temperature can choose CAP-GW) |
| Zero Temp.Drift | ±0.03%FS/℃ |
| Sensitivity Temp.Drift | ±0.03%FS/℃ |
| Long Term Stability | ≤0.2%FS/year |
| Response Speed | ≤1ms(up to 90%FS) |
| Process Connection | M20×1.5、G1/2、G1/4、NPT1/2 or Customized |
| Ingress Protection | IP65 |
|
CAP -2088XS-ð-ð-ð-ð-ð-ð-ð-ð |
Code | |||||||
|
Range |
-0.1～0-0.02～100MPa |
R | ||||||
|
Type |
Gauge (G) |
G | ||||||
|
Absolute (A) |
A | |||||||
|
Sealed Gauge (S) |
S | |||||||
|
Output |
4~20mA |
V1 | ||||||
|
0~5V DC |
V2 | |||||||
|
1-5V DC |
V3 | |||||||
|
Hart, RS485,RS232（optional） |
V4 | |||||||
|
Connection |
M20×1.5 |
B1 | ||||||
|
1/4NPT |
B2 | |||||||
|
G1/2 |
B3 | |||||||
|
G1/4 |
B4 | |||||||
|
Customized |
B5 | |||||||
|
Accuracy |
0.5%FS |
C1 | ||||||
|
0.25%FS |
C2 | |||||||
|
0.1%FS |
C3 | |||||||
|
Material |
304SS |
M1 | ||||||
|
316LSS |
M2 | |||||||
|
Ex-proof |
No explosion-proof |
0 | ||||||
|
Ex | ||||||||
