| Pressure Range | -0.1～0～6MPa |
| Medium | Sanitary Liquid,Gas,Oil etc. |
| Pressure Type | Gauge (G), absolute (A), sealed gauge (S) |
| Accuracy | ±1%FS,±0.5%FS,±0.25%FS, |
| Working Temperature | -20℃~65℃ |
| Power Supply | DC24V(12V～36V) |
| Sinnal Output | 4～20mA、0～5VDC、1～5VDC、0～10VDC RS485 |
| Load Capacity | Current Output≤500Ω;Voltage Output≥3Ω |
| Nonlinearity | ±0.2%FS |
| Hysteresis and Repeatability | ±0.1%FS |
| Long-term Stability | ±0.1%FS |
| Thermal Zero Per Degree Drift | ±0.02%FS |
| Respone Time | 8ms |
| Maximum Working Pressure | 2 Times Range |
| Electrical Connections | Hirschaman Connection,Plug Connector,Waterproof Cable Connector |
| Pressure Interface | M20×1.5、G1/2、G1/4、NPT1/2 or Customized |
| Shell Material | SS304 or SS316 |
| Protection Grade | IP65 |
