| Temperature Range | Type K (Ni-Cr/Ni-Si) [-40~1000℃(-104~1832°F)] |
| Type N (Ni-Cr-Si/Ni-Cr-Mg) [-40~800℃(-104~1472°F)] | |
| Type T (Cu/Cu-Ni) [-200~300℃(-328~572°F)] | |
| Type E (Ni-Cr/Ni-Cu) [-200~700℃(-328~1292°F)] | |
| Type J (Fe/Cu-Ni) [-40~600℃(104~1112°F)] | |
| Accuracy | Class A or Class B. |
| Diameter | φ0.25, φ0.5, φ1.0, φ2.0, φ3.0, φ4.0, φ5.0, φ6.0, φ7.0, φ8.0. Need bigger diameter, thermowell should be added. |
| Material | 304,316,316L,GH3030,GH3039,Inconel600. |
| Lead Wires | 24 AWG Wire,FEP Insulated,Color coded per IEC 60584 or ASTM E230. |
| Junction Box | Cast aluminium stainless steel,Stainless steel junction box,Plastic junction box. |
| Insulation Resistance | 1000MΩMinimum insulation resistance when measured at 500VDC at room temperature. |
